6063 aluminum flat bar has excellent thermoplasticity, good weldability, and corrosion resistance, and can be rapidly extruded into various structurally complex profiles. It is suitable for manufacturing building profiles, irrigation pipes, and extrusion materials for vehicles, furniture, fences, etc.
Item No :
6063 aluminum flat barProduct Origin :
ChinaTemper :
H112,T6,T651,T5,T4,OStandard :
ASTM ，AMS, GB/T ，EN 485Order(MOQ) :
1 pcsThickness :
1.5-90MM / CustomizedLength :
100mm/ 200mm / Customized sizeMill certificate :
Each batch of materials can be providedPayment :
T/T, L/CDelivery Time :
1-2 days (stock) / 15-25 days (no stock)
6063 aluminum fat bar is a material widely used in building aluminum doors and windows, curtain wall frames, irrigation pipes, and precision instruments. It has good formability and moderate strength, which can meet most building requirements and is also suitable for fields such as aerospace fixtures and automated mechanical parts
Please refer to the following Chemical Composition(%):
| Chemical Composition |
Element | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other each | Total each | Al |
| Standard value(%) |
0,20-0,6
|
≤0,35 | ≤0.1 | ≤0.1 |
0.45-0.9
|
≤0,1
|
≤0.1 | ≤0.1 | ≤0.05 | ≤0.15 | Rest |
Please refer to the following Mechanical Property:
| Mechanical Property |
Parameter | Tensile strength resistance(Mpa) | Yield strength(Mpa) | Elongation(%) | Hardness(HBW) | |||||||||
| Standard value | ≥215 | ≥170 | ≥10 | ≥75 | ||||||||||
For more product information, please refer to the following list：
| Service | Cutting, Leveling, machining, finish process, grinding, custom |
| Packing details | Wooden pallet & box |
| Supply ability | 100MT/month |
| Incoterm | EXW, FOB, CIF, DDP... |
| Shipping methond | By sea/air/truck/DHL... |
